Model FADC-PN30-10mA
This series of dual-output positive & negative high-voltage DC power supplies adopts a fully digital intelligent control architecture, which precisely meets customers' diverse control settings and functional requirements. Featuring excellent transient response of voltage and current, it quickly suppresses fluctuations under various operating conditions to ensure long-term stable and fault-free operation. Equipped with comprehensive functions, the unit provides wide-range and high-precision adjustable dual positive/negative outputs with strong compatibility. An optional RS485 communication interface is available to flexibly integrate customized requirements, perfectly complying with the strict application standards of various industrial scenarios.
| Power Supply Parameters | |
|---|---|
| Input Voltage | AC 220V±10% 50/60Hz Mains Power |
| Frequency | 50Hz±1% |
| Output DC Voltage | 5kV, 10kV, 20kV, 30kV |
| Output Current | 1mA, 5mA, 10mA |
| Output Power | Max. 300W |
| Ripple Voltage | ≤ 1% |
| Load Regulation | Standard: 3-5% |
| Line Regulation | Standard: 3-5% |
| High Voltage Stability | ±0.1% per hour after 30 minutes of warm-up |
| Temperature Coefficient | 100ppm / ℃ |
| Ambient Temperature | -25～+55℃ |
| Tilt Angle | >45° |
| Operating Environment | No conductive substances, no corrosive metal liquid, no condensation |
| Power Supply Weight | ≈13kg |
